PE/N terminal for installation in GTA distribution boards as additional terminals or for replacement
1 module, Grey, 76 A, 2 x 25 mm² + 14 x 4 mm² for NS 35
This article is archived!
Terminal
KLS 35-SL
Productnumber: 07422601 | Dimensions: 58 x 53 x 23,8 mm
electrical characteristics
| Rated operating voltage AC | 450 V |
|---|---|
| Rated current | 76 A |
| Number of poles | 1 |
| shockproof | Yes |
| Connection 1: Connection type | Screws |
| Connection 1: Clamping points per pole | 2 |
| Connection 1: Suitable for Cu conductors | 1 |
| Connection 1: Connectable conductor cross-section, fine-wire with ferrule (min) | 2.5 mm² |
| Connection 1: Connectable conductor cross-section, fine-wire with ferrule (max) | 16 mm² |
| Connection 1: Connectable conductor cross-section, single-wire (min) | 2.5 mm² |
| Connection 1: Connectable conductor cross-section, single-wire (max) | 25 mm² |
| Connection 1: Connectable conductor cross-section, stranded (min) | 2.5 mm² |
| Connection 1:Connectable conductor cross-section, stranded (max) | 25 mm² |
| Connection 2: Connection type | Screwless |
| Connection 2: Stripping length | 10 mm |
| Connection 2: Clamping points per pole | 14 |
| Connection 2: Suitable for Cu conductors | 1 |
| Connection 2: Connectable conductor cross-section, fine-wire with ferrule (min) | 0.5 mm² |
| Connection 2: Connectable conductor cross-section, fine-wire with ferrule (max) | 4 mm² |
| Connection 2: Connectable conductor cross-section, single-wire (min) | 0.5 mm² |
| Connection 2: Connectable conductor cross-section, single-wire (max) | 4 mm² |
Dimensions
| Width | 58 mm |
|---|---|
| Length | 53 mm |
| Height | 23.8 mm |
| Weight | 0.047 kg |
Material characteristics
| Flammability class according with UL94 | V0 |
|---|---|
| Glow-wire flammability according to EN 60695-2-11 | 960 °C |
Sales Information
| EAN | 4013902992867 |
|---|---|
| Packing Unit Code | C62 |
| ETIM Class | EC001284 |
| Custom tariff number | 85369010 |
