P 71 GRO

P 71 GRO

P 71 GRO

Large conduit box

P 71 GRO

Productnumber: 98407501 | Dimensions: 71 x 71 x 76,5 mm

Large conduit box , especially for horizontal factory finishing, 1-part, diameter 60 mm Ø, 4 screw bosses with a 60 mm screw spacing, combinable, suitable for opposing formwork, combinable with a standard spacing of 71 mm, protection class IP30, rated insulation voltage: 400V AC, certified by VDE (DIN EN 60670-1/-22 (VDE 0606-1/-22)), Halogen free

with enlarged terminal compartment, for 50mm HM-UNI magnetic clamp (97929901), magnet installation, conduit adapter and additional conduit adapter with Easy-Cut-Membran, sealing range M32 - M40, support spar compatible

electrical characteristics

Rated insulation voltage AC	400 V
Type of protection	IP30
Suitable for	Concrete construction
UL Type Rating	not specified

Dimensions

Width	71 mm
Length	71 mm
Height	76.5 mm
Inner height	72.9 mm
Weight	0.061 kg

Material characteristics

Halogen free	yes
Flammability class according with UL94	HB
Glow-wire flammability according to EN 60695-2-11	650 °C

mechanical properties

Type of fastening	magnet installation

Ambient conditions

max. relative humidity 40°C	50 %
Min. ambient temperature	-25 °C
Max. ambient temperature	40 °C
24h ambient temperature	35 °C

Sales Information

EAN	4013902597505
Packing Unit Code	C62
ETIM Class	EC002601
Custom tariff number	39269097

Material

Base unit material	Plastic
Cover material	Polypropylene

Certificates

Test mark	VDE (DIN EN 60670-1/-22 (VDE 0606-1/-22))

Download Data Sheet

Download Data Sheet

Installation instructions

Assembly instruction NL	pdf (913 KB)
Assembly instruction ES	pdf (914 KB)
Assembly instruction DE	pdf (913 KB)
Assembly instruction EN	pdf (914 KB)
Assembly instruction FR	pdf (914 KB)

Dimensioned drawing

Dimensional drawing	pdf (308 KB)
Dimensional drawing	dxf (3 MB)
Dimensional drawing	dwg (638 KB)
Dimensional drawing	jpg (1 MB)

Certificate

VDE Certificate (DIN EN 60670) DE/EN	pdf (627 KB)
UKCA Declaration EN	pdf (49 KB)
CE Declaration DE/EN/FR	pdf (62 KB)
CE Declaration DE/EN/PL	pdf (74 KB)
