Cable gland, IP68, with strain relief, polyamide, M_ x 1.5 mm, with locknut, orange
Sealing range 16 - 28 mm, Thread length 11 mm
Cable gland
KVR M40-MGM/or
Productnumber: 22764001 | Dimensions: 50 x 50 x 54 mm
electrical characteristics
| Type of protection | IP68 |
|---|
Colours
| Accessory colour | reinorange |
|---|
Dimensions
| Width | 50 mm |
|---|---|
| Length | 50 mm |
| Height | 54 mm |
| Nominal size | M40 |
| Weight | 0.05 kg |
Material characteristics
| UV-resistant | yes |
|---|---|
| Halogen free | yes |
| Flammability class according with UL94 | V2 |
| Glow-wire flammability according to EN 60695-2-11 | 850 °C |
mechanical properties
| for sealing range min | 16 mm |
|---|---|
| for sealing range max | 28.0 mm |
Ambient conditions
| Installation location | unprotected outdoor areas |
|---|
Sales Information
| EAN | 4013902815890 |
|---|---|
| Packing Unit Code | C62 |
| ETIM Class | EC000441 |
| Custom tariff number | 39269097 |
CAD-Data
| CAD-Data | Download 3D-CAD-Data |
|---|
